Model Name:STEED600
Manufacturer:HONDA
Model Year:1988
It was a cruiser model that had an elaborated frame design and a swing arm structure. Its engine was wrapped around with a triangular silhouette frame. The suspension was stored under the seat to make the rear have a rigid style.
Specifications:
[Basic spec]
| Manufacturer | HONDA | Engine Type | Water-Cooled 4 Cycle OHC 3-Valve V-Shaped 2 Cylinder |
|---|---|---|---|
| Model Name | STEED600 | Starter | – |
| Grade | – | Maximum Output (ps) | 30ps(22kw)/7500rpm |
| Drive Train | – | Maximum Torque (kgf/m) | 3.3kg-m(32.4N-m)/5500rpm |
| Model Type | PC21 | Curb Weight | 208 |
| Displacement | 583 | Dry Weight | 205(Approximate Value) |
| Sales Launch Year | 1988/0 | Fuel Efficiency by Catalog | – |
| Height/Width/Length | 1130/-/2310 | Fuel Tank Capacity | – |
| Seat Height | – | Distance to Empty | – |
| Front Tire Indication | 100/90-19 57S | Fuel Supply | Carburetor |
| Rear Tire Indication | 170/80-15 77S WT |
[Service data]
| Standard Plug | DPR7EA-9 | Chain Size | 525 |
|---|---|---|---|
| Number of Used Plugs | 4 | Chain Link Number | 120 |
| Engine Oil Amount | – | Battery Code | – |
| Engine Oil (Refill) | 2.1L | Headlight | 12V 60w/55w |
| Engine Oil (Element Replacement) | 2.25L | Headlight Type | H4 |
| Front Blinker Rating | 12V 23w/8w | Headlight Remarks | – |
| Drive Sprocket Teeth Number | 16 | Tail Light Rating | 12V 23w/8w |
| Driven Sprocket Teeth Number | 45 | Rear Blinker Rating | 12V 23w |
[Machine detail]
| Motor Model Code | PD06E | Caster Angle | – |
|---|---|---|---|
| Bore (mm) | – | Trail (mm) | – |
| Storke (mm) | – | Minimum Ground Clearance | – |
| Compression Ratio | – | Distance Between Axes | – |
| Ignition Method | – | Streering Angle (Right) | – |
| Engine Lubrication Type | – | Turning Angle (Left) | – |
| Frame Type | – | Mirror Screw Hole Diameter | 10mm |
| Minimum Rotaion Radius | – | Fuel Tank Reserve Capacity | – |
[Underbody detail]
| Front Brake Type | Single Disc | Suspension Type (Rear) | – |
|---|---|---|---|
| Front Brake Remarks | – | Number of Rear Shock Absorbers | – |
| Rear Brake Type | Drum | Rear Suspension Stroke | – |
| Rear Brake Remarks | – | Rear Wheel Travel | – |
| Suspension Type (Front) | – | ABS | – |
| Front Fork Type | – | Drive Train | Chain |
| Front Suspension Stroke | – | Differential Oil Amount | – |
| Front Fork Diameter | – | Chain Remarks | – |
[Equipment]
| Seat Lowering Allowance | – | Theft Prevention Device | – |
|---|---|---|---|
| Mirror Screw Hole Diameter | 10mm | Tail Light Bulb Type | S25 |
| Mirror Remarks | – | Tail Light Base Shape | BAY15D |
| Electronic Device Remarks | – | Tail Light Base Shape 2 | – |
| Fuel Gauge | – | Tail Light Remarks | – |
| Clock | – | Front Blinker Bulb Type | S25 |
| Hazard | – | Front Blinker Base Shape | BAY15D/BA15S |
[Engine detail]
| Clutch Type | – | Tappet Clearance (mm) EX | – |
|---|---|---|---|
| Transmission | – | Idling Initial Value (rpm) | – |
| Number of Gears | – | Needle Steps (Clip Location) | – |
| Gear Ratio | – | Float Level (mm) | – |
| Primary Reduction Ratio | – | Air Screw Return | – |
| Secondary Reduction Ratio | 2.813 | Main Jet Type | KEIHIN Round Large (E) |
| Variable Speed Vehicle Gear Ratio | – | Main Jet Number | #95 |
| Tappet Clearance (mm) IN | – |
[Other spec]
| Clutch Cable Length | 1030 | Rear Brake Cable Length | – |
|---|---|---|---|
| Choke Cable Length | – | Other Cables | Direct (L)1020 |
| Meter Cable Length | 1000 | Engine Number (Production Launch) | – |
| Throttle Cable Length | 880/880 | Engine Number (Production End) | – |
| Front Brake Cable Length | Direct (L)1020 |
