Model Name:NC750X TYPE LD
Manufacturer:HONDA
Model Year:2014
Make your motorcycle look and move as you wish. Try the new crossover feel with this “NC750X”. “NC750X” is based on the “crossover concept” that blends the joy of seeking the new possibility without sticking to one category. Its design is dynamic and powerful. Its upright position offers comfort on streets and moving power that expands the scope of activities. It also adopts a long stroke suspension (front: 153.5mm cushion stroke, 150mm rear axle travel) to make the rider enjoy all sorts of ride.
Specifications:
[Basic spec]
| Manufacturer | HONDA | Engine Type | Water-Cooled 4 Stroke 2 CylinderOHC 4-Valve |
|---|---|---|---|
| Model Name | NC750X TYPE LD | Starter | Self Starter |
| Grade | ABS | Maximum Output (ps) | 54ps(40kw)/6250rpm |
| Drive Train | – | Maximum Torque (kgf/m) | 6.9kg-m(68N-m)/4750rpm |
| Model Type | RC72 | Curb Weight | 219 |
| Displacement | 745 | Dry Weight | 200(Approximate Value) |
| Sales Launch Year | 2014/1 | Fuel Efficiency by Catalog | 42.0 km/L (at 60 km/h) |
| Height/Width/Length | 1255/140/2195 | Fuel Tank Capacity | 14 |
| Seat Height | 800 | Distance to Empty | – |
| Front Tire Indication | 120/70ZR17 58W | Fuel Supply | Injection |
| Rear Tire Indication | 160/60ZR17 69W |
[Service data]
| Standard Plug | – | Chain Size | – |
|---|---|---|---|
| Number of Used Plugs | – | Chain Link Number | – |
| Engine Oil Amount | – | Battery Code | – |
| Engine Oil (Refill) | – | Headlight | – |
| Engine Oil (Element Replacement) | – | Headlight Type | – |
| Front Blinker Rating | – | Headlight Remarks | – |
| Drive Sprocket Teeth Number | – | Tail Light Rating | – |
| Driven Sprocket Teeth Number | – | Rear Blinker Rating | – |
[Machine detail]
| Motor Model Code | RC70E | Caster Angle | 27.0 Degrees |
|---|---|---|---|
| Bore (mm) | 77 | Trail (mm) | 110 |
| Storke (mm) | 80 | Minimum Ground Clearance | 140 |
| Compression Ratio | 10.7 | Distance Between Axes | 1525 |
| Ignition Method | Transistor Ignition | Streering Angle (Right) | – |
| Engine Lubrication Type | Force Feeding & Splash | Turning Angle (Left) | – |
| Frame Type | Diamond/Backbone Frame/Twin Spar | Mirror Screw Hole Diameter | 8mm |
| Minimum Rotaion Radius | 3 | Fuel Tank Reserve Capacity | – |
[Underbody detail]
| Front Brake Type | Single Disc | Suspension Type (Rear) | Swing Arm |
|---|---|---|---|
| Front Brake Remarks | – | Number of Rear Shock Absorbers | – |
| Rear Brake Type | Disc | Rear Suspension Stroke | – |
| Rear Brake Remarks | – | Rear Wheel Travel | – |
| Suspension Type (Front) | Telescopic | ABS | Available |
| Front Fork Type | – | Drive Train | Chain |
| Front Suspension Stroke | – | Differential Oil Amount | – |
| Front Fork Diameter | – | Chain Remarks | – |
[Equipment]
| Seat Lowering Allowance | – | Theft Prevention Device | Available |
|---|---|---|---|
| Mirror Screw Hole Diameter | 8mm | Tail Light Bulb Type | – |
| Mirror Remarks | – | Tail Light Base Shape | – |
| Electronic Device Remarks | – | Tail Light Base Shape 2 | – |
| Fuel Gauge | Available | Tail Light Remarks | – |
| Clock | Available | Front Blinker Bulb Type | – |
| Hazard | Available | Front Blinker Base Shape | – |
[Engine detail]
| Clutch Type | Wet Type | Tappet Clearance (mm) EX | – |
|---|---|---|---|
| Transmission | Normal Shift | Idling Initial Value (rpm) | – |
| Number of Gears | 6 | Needle Steps (Clip Location) | – |
| Gear Ratio | 2.812 / 1.894 / 1.454 / 1.200 / 1.033 / 0.837 | Float Level (mm) | – |
| Primary Reduction Ratio | 1.731 | Air Screw Return | – |
| Secondary Reduction Ratio | 2.529 | Main Jet Type | – |
| Variable Speed Vehicle Gear Ratio | – | Main Jet Number | – |
| Tappet Clearance (mm) IN | – |
[Other spec]
| Clutch Cable Length | – | Rear Brake Cable Length | – |
|---|---|---|---|
| Choke Cable Length | – | Other Cables | – |
| Meter Cable Length | – | Engine Number (Production Launch) | – |
| Throttle Cable Length | – | Engine Number (Production End) | – |
| Front Brake Cable Length | – |
